Victoria Chair Lift
Brand:
Sesame Access
Country of Origin:
United Kingdom
Sample Available: No
For product pricing, customization or other inquiries:
Request for Price
Sesame Access Systems
-
United Kingdom
- Service Provider
- Founded: 1996
-
Website:
www.sesameaccess.com -
Location:
Unit 1, Cumberland Works, Wintersell Business Park, West Byfleet
Surrey
Specifications
Minimum horizontal pit length
1472 mm
Minimum platform size
1408 x 1058 mm
Maximum rise
999 mm
Minimum pit depth below lower landing
1065 mm + cladding & bedding
Features
The Victoria Chair Lift uses our wheel stop mechanism. A solid stainless steel toe guard that rises around the platform to prevent wheelchair wheels from rolling off the lift. Please see on lift barriers for more information.
The lift table can be made to accept any cladding material. The stairs lower to create the platform, therefore the stair cladding makes up most of the lift table finish.
Nominal platform dimensions for this lift can vary due to site requirements. However, they are more than or equal to:
1477 mm (l) x 1144 mm (w) 0 – 999 mm (h)
The platform can have a button post for independent control or a removable hand-held post that is inserted by a member of staff.
The stairs
The Victoria Chair Lift has stairs that raise and lower vertically thus removing the requirement for a pit behind the top step riser.
The top step riser is not a moving stair, it is formed as part of the upper landing area. For example, a staircase with six risers will have five vertically retracting stairs that will lower.
When the stairs lower the surrounding stair profile will be revealed. Typically this is clad in stainless steel as it is not seen when the stairs are in their resting position. This side stair profile houses a locking mechanism that stabilises and supports the stairs when they are in their resting position.
The upper landing barrier
The Victoria Chair Lift houses a manual gate at the upper landing to protect against the fall hazard that is created when the stairs retract.
User type
The Victoria Chair Lift is for wheelchair users only. Non wheelchair users are often presented with a wheelchair to travel whilst seated on this wheelchair platform stair lift. Please see on lift barriers for more information.
